KP-1000 Pure sine wave power inverter
詳細介紹
Specification:
· Model No：KP-1000 · Voltage In：DC 12V.24V.48V · Voltage Out：AC115V.220V.230V.240V · Continuous Power：1000W · Peak Power：2000W for 1 Cycle · Output Frequency：50 or 60Hz · Output Waveform：Pure Sine Wave | · No Load Current Draw：≦0.8A · Efficiency：85% · Fuse：30A*3 · Weight：2.6 kgs · Dimension：310*150*70 mm(L*M*H) |
Input voltage | DC12V | DC24V | DC48V | Warning light | Warning tone |
Voltage Range | 10.5~15.5V | 21~32V | 42~62V | ||
Low-voltage warning | 10.8+/-0.2V | 21.6+/-0.4V | 43.2+/-0.8V | Blinks twice | Alarm twice |
Low Voltage protection | 10.2+/-0.2V | 20.4+/-0.4V | 40.8+/-0.8V | Blinks 3 time | Alarm 3 times |
High voltage protection | 15.5+/-0.2V | 31+/-0.4V | 62+/-0.8V | Blinks 4 time | Alarm 4 times |
Overheating | 75℃ | 75℃ | 75℃ | Blinks 5 time | Alarm 5 times |
Overload | Over 120% | Flashes | NO | ||
Input Reverse | Fuse | NO | NO | ||
Short protection | Stop output | Flashes | NO | ||
